UL Unarmored Tray, TC-ER, Helical Copper Tape Shielded, Control, XLPE/PVC | Multi-Conductor (600V)

Shawflex UL Tray Helical Copper Tape Shielded Control cables offers the best effective way to protect your electrical property against the interference through induction and capacitive coupling in the complex electric magnetic field, for example in the substation environment. Permitted for Exposed Run (ER) use in accordance with NEC, reducing installation cost and time. Offering superior performance in harsh environment with all color sunlight resistance jacket, -40°C cold bend, and oil resistance.
Certification Logo
Datasheet (PDF) Contact Us

Construction

Voltage

600 V

Product Construction



    • Conductor:
      • 14 AWG through 10 AWG fully annealed standard bare copper per Class B ASTM B8 stranding



    • Insulation:
      • Cross-linked Polyethylene (Type XHHW-2). 90°C DRY/WET



    • Metallic Shield:
      • Overall Helical 5mil copper tape



  • Jacket:
    • Polyvinyl Chloride (PVC), Sunlight Resistant in all colors

COLOUR CODING

  • Color-coded per ICEA Method 1, Table E-2

*Optional color codes are available

LEGEND

  • SHAWFLEX 3C XX AWG 600V (UL) TC-ER
  • XHHW-2 90C WET/DRY SUN RES DIRECT BURIAL
  • IEEE 1202/FT4 90C PVC JACKET OIL RES I
  • MADE IN CANADA
  • Part # (mo#) (month year)
  • (sequential footage marking every 2 feet)

Certifications

Certifications/Compliances



  • UL 1277, Tray Cable (TC-ER)
  • UL 44 Type XHHW-2
  • IEEE 1202/FT4, UL 1685
  • ICEA T-29-520
  • UL 1581/UL 2556 VW-1
  • SUN RES in all colors
  • DIR BUR
  • -40ºC Cold Bend
  • OIL RES I

Properties



  1. Stranded Bare (ASTM B8) Annealed Copper Conductors (Tinned Available)
  2. FR XLPE (XHHW-2 Rated) Insulated Conductors
  3. Overall Helical 5mil Copper Tape
  4. Polyvinyl Chloride (PVC) Jacket
Part Number Conductor Count Conductor Size Nominal Overall Diameter Of Cable Cable Weight Ampacity 30°C Ambient Max. Pulling Tension (Pulling Eye) Min. Bend Radius (Pull)
AWG IN LBS/1000FT AMPS LB IN

2V01HU140200201

2

14

0.40

106

25

66

7.13

2V01HU140300201

3

14

0.42

127

25

99

7.50

2V01HU140400201

4

14

0.45

154

20

132

8.12

2V01HU140500201

5

14

0.49

178

20

164

8.80

2V01HU140600201

6

14

0.53

207

20

197

9.52

2V01HU140700201

7

14

0.53

222

17.5

230

9.52

2V01HU140800201

8

14

0.60

268

17.5

263

10.78

2V01HU141000201

10

14

0.69

329

12.5

329

12.46

2V01HU141200201

12

14

0.71

369

12.5

395

12.82

2V01HU141400201

14

14

0.75

416

12.5

460

13.44

2V01HU141600201

16

14

0.79

460

12.5

526

14.13

2V01HU142000201

20

14

0.90

592

12.5

658

16.29

2V01HU143000201

30

14

1.05

817

11.25

986

18.95

2V01HU144000201

40

14

1.17

1036

10

1315

21.08

2V01HU145000201

50

14

1.30

1260

8.75

1644

23.33

2V01HU120200201

2

12

0.43

133

30

104

7.78

2V01HU120300201

3

12

0.46

165

30

157

8.20

2V01HU120400201

4

12

0.49

199

24

209

8.90

2V01HU120500201

5

12

0.57

253

24

261

10.22

2V01HU120600201

6

12

0.61

295

24

313

11.03

2V01HU120700201

7

12

0.61

319

21

366

11.03

2V01HU120800201

8

12

0.66

353

21

418

11.85

2V01HU121000201

10

12

0.76

436

15

522

13.75

2V01HU121200201

12

12

0.79

496

15

627

14.16

2V01HU121400201

14

12

0.83

559

15

731

14.87

2V01HU121600201

16

12

0.91

654

15

836

16.37

2V01HU122000201

20

12

1.00

796

15

1045

18.01

2V01HU123000201

30

12

1.17

1114

13.5

1567

21.02

2V01HU124000201

40

12

1.30

1424

12

2090

23.44

2V01HU125000201

50

12

1.44

1743

10.5

2612

26.00

2V01HU100200201

2

10

0.48

173

40

166

8.68

2V01HU100300201

3

10

0.51

218

40

249

9.17

2V01HU100400201

4

10

0.58

287

32

332

10.53

2V01HU100500201

5

10

0.64

338

32

415

11.43

2V01HU100600201

6

10

0.69

396

32

498

12.38

2V01HU100700201

7

10

0.69

432

28

581

12.38

2V01HU100800201

8

10

0.74

484

28

664

13.33

2V01HU101000201

10

10

0.90

632

20

830

16.27

2V01HU101200201

12

10

0.93

721

20

996

16.75

2V01HU101400201

14

10

0.98

818

20

1163

17.57

2V01HU101600201

16

10

1.03

907

20

1329

18.49

2V01HU102000201

20

10

1.13

1114

20

1661

20.39

2V01HU103000201

30

10

1.33

1576

18

2491

23.91

2V01HU104000201

40

10

1.48

2028

16

3322

26.73

2V01HU105000201

50

10

1.65

2494

14

4152

29.71

*Ampacity value based on National Electrical Code, Version 2017, Table 3-10.15(B)(16). Values are corrected according to Table 310.15(B)(3)(a) for number of Conductors.
